CREWORKS 20 Ton 30HP Industrial Air-Cooled Water Chiller with 66 gal. Water Tank
Specifications
| Return Shipping Will Be Paid By | Seller |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Refund Will Be Given As | Money Back |
| Brand | CREWORKS |
| MPN | CWTH-20 |
| Product | Air-cooled Chiller |
| Color | White, Gray |
| Input Voltage | 480V/60Hz |
| Compressor Power | 14.8 hp x 2 (11.1 kWx2) |
| Fan Power | 1.4 hp x 2 (1.1 kW x 2) |
| Water Pump Power | 3 hp (2.3 kW) |
| Max. Working Temperature | 113°F (45°C) |
| Cooling Capacity | 60 kW (51600 Kcal/hr.) |
| Tank Capacity | 66 gal. (250 L) |
| Max. Pump Lift | 62.3 ft. (19 m) |
| Inlet/Outlet Port Diameter | 2 in. (5.1 cm) |
| Net Weight | 1235 lb. (560 kg) |
| Warranty | 1 Year |
FeaturesApplicable IndustriesApplicable IndustriesSpec ComparationModelCWTH-5CWTH-6CWTH-8Input Voltage480V/60Hz480V/60Hz480V/60HzCompressor Power7.5 hp (5.6 kW)9 hp (6.7 kW) 12.3 hp (9.2 kW)Refrigeration Capacity12900 Kcal/hr. (15 kW)15480 Kcal/hr. (18 kW)20640 Kcal/hr. (24 kW)Tank Capacity16 gal (60 L)16 gal (60 L)37 gal (140 L)Water Pump Power1 hp (0.75 kW)1 hp (0.75 kW)1 hp (0.75 kW)Max. Flow29 gpm (110 L/min)29 gpm (110 L/min)53 gpm (200 L/min) Dimensions51×24×48 in.51×24×48 in.63×29×55 in.ModelCWTH-15CWTH-20CWTH-30Input Voltage480V/60Hz480V/60Hz480V/60HzCompressor Power22 hp (16.5 kW)29.6 hp (22.2 kW)44.4 hp (33.3 kW)Refrigeration Capacity38700 Kcal/hr. (45 kW)51600 Kcal/hr. (60 kW)77400 Kcal/hr. (90 kW)Tank Capacity53 gal (200 L)66 gal (250 L)98 gal (370 L)Water Pump Power2 hp (1.5 kW)3 hp (2.25 kW)5 hp (3 kW)Max. Flow95 gpm (360 L/min)79 gpm (300 L/min)145 gpm (550 L/min)Dimensions70×33×62 in.75×34×69 in.106×38×69 in.On Apr 24, 2024 at 06:38:22 PDT, seller added the following information:
